PF2W520-N04N

Description

PF2W is a digital flow sensor for water or coolant.  This is a legacy sensor, refreshed in 2009 as PF3W.  This is the remote version of PF2W7, with a display.  The mounting bracket is integrated into the body, while the M12 lead wire is optional.  PF2W5 can be paired with a PF2W200 or PF2W300 remote monitor to display instantaneous or accumulated flow values.  An optional analog output is also available.  PF2W5 is IP65 rated and CE compliant. - Flow ranges (lpm): 0.5-4, 2-16, 5-40, 10-100 - Port sizes (Rc, NPT, G): 3/8, 1/2, 3/4, 1 (flow range dependent) - Temperature rating: 0-50°C - Output options: 1-5V, 4-20mA - Accuracy: ±5% F.S. or ±3% F.S. (flow range dependent) - Repeatability: ±3% F.S.
