AN101-N01

Description

Series AN silencers offer various styles and low back pressure in a compact, easy mounting design. The noise reduction has been improved to 30 dB(A) and the case is UL94-V0 grade, flame resistant material. Series AN is available with M, R or NPT threads. - Fluid: compressed air - Maximum operating pressure: 1.0MPa - Noise reduction: 13-21 dB(A) - Effective area mm 2 : 1-20 - Ambient & fluid temperature: 5 - 50° C
